Description
New Swiss X2 motor
Exclusive for the X2 models. Hi-performance motor with 6W mechanical output. High energy efficiency (86%). Optimal for battery operation with the RPS-600. Runs all type of standard and cartridge needles*.
New 4mm stroke stainless steel cam
The standard cam has been replaced with a new 4mm stroke cam made from stainless steel to enhance durability and lining performance. Cams can be exchanged like before. Four different cams are available for purchase as a kit. The new 4mm steel cam comes as standard.Use tool kit No.90 for quick and easy cam change.
Easy to convert between standard and cartridge needles
When using cartridges the Stay up spring must be removed to prevent strain on the motor and to function properly. The X2 version has a lid in the frame that allows quick access to the Stay up spring. Easy to remove and insert when choosing between standard and cartridge needles.
More stable give adjustment
New Cap with built in damper prevents clatter and excessive noise when using the softer give settings. Allows to use the whole 3 turns adjustment efficiently and without clatter.
Higher precision and finish
The X2 models have several improvements regarding component materials and precision.
- Lightweight (85 grams)
- Silent
- Low vibrating
- Ergonomic
- Don’t need rubber bands
- Adjustable hitting force
- Accepts standard grips, tubes and needles
- Compatible with cartridge needles
- Both clip cord & RCA connections
- Works with most power supplies 0-13V
- Exchangeable cams
- Normally stops in upper position
- No moving components in contact with plastic barrier
- High durability
- Wireless ready for RPS-600
Input voltage: 0-13 volt DC (max 13 volt DC)
Power connections: RCA or clip cord (max. clip cord end diam Ø1.6mm)
Rpm range stitches/sec: 0-8 000 rpm/min 0-130/sec
Stroke length: 2.6 - 3.5 mm depending on cam used
Suspension stroke: 0-2mm
Max. tube diam Ø: Ø8mm
Max. needle size: 50 magnum
Weight: 85 grams
Wireless ready: Yes
Dimensions LxBxH: 95 x 21 x 77mm
Warranty
Shipping & Returns
All deliveries are sent by Australia Post with the choice of Express or Parcel post at checkout. Delivery charges are calculated using actual Australia Post rates. Please checkout here for more info
Product specification
Conventional Liner: As our most popular machine style this tool is meant to be used as an everyday ''workhorse'' style of machine for all around tattooing. This machine will typically be used for tight 3rls-14rls.
Introducing the newly designed Ink Machines, the latest coil machine design from Ink Machines!
An all new Ink Machinesmechanism with 5 point clamping provides a secure grip on all standard metal and disposable tubes.
The inlaid steel rear yoke provides increased connection and multiple positioning options for ultimate contact with clip cords.
Made of Aircraft grade aluminum, the fully assembled machine weighs only 4.85 ounces.
The Roswell is available as a Conventional Liner, Power Liner, Soft Shader, and Color Packer.
This machine is available tuned as a Conventional Liner, Power Liner, Soft Shader and Color Packer.
Engineered and manufactured in the USA by FK Irons.
